Oval Medallion Dark Walnut Steel Door C-TR700

Product CodeC-TR700

Dark walnut flat entrance door with an embossed oval medallion and a floral lower panel. Product code: C-TR700. Made to measure after an on-site survey.

Leaf construction: single leaf
Color / finish: dark walnut
Glass: Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant)
Handle: gold knocker and horizontal handle
Design language: classic
Upper section: frame with pediment

Share this model

Pre-Order & Price Request

This model is made to measure. Leave your request and we'll call you to arrange a site survey.

Product codeC-TR700

Survey and measurement are free
Same-day response
Made in our own factory
Lifetime manufacturing warranty

+90 532 689 21 46 WhatsApp

Download this model's PDF spec sheet

Worldwide shipping & export

Made in our own factory

Lifetime manufacturing warranty

#steel door #flat entrance steel door #c-tr700 #classic #made-to-measure steel door #classic design #wood tone #single leaf

A dark walnut flat entrance door with an embossed oval medallion and a floral lower panel. Listed in our catalog under code C-TR700. It is not sold in stock sizes; your entrance is measured on site and the leaf is manufactured to that exact measurement.

Product Code: C-TR700

Surface and Pediment Layout

The leaf layout is a single leaf. The leaf carries an embossed oval medallion and a floral motif below. The catalog color is a dark walnut tone.

The upper section features a pedimented frame. The hardware is a gold knocker with a horizontal handle. Color, pattern and handle choices can be tailored to your project; the cladding options page compares what is available.

Its design language is defined as classic.

Who Is This Model For?

Flat entrances and apartment homes are where this model is typically used. The single-leaf layout adapts directly to conventional door openings.

Measurement, Production and Installation

Measurements are taken from the door opening, not the existing leaf; we describe the process step by step on our how to measure page. Frame, sheet thickness, infill and lock values are listed in the specification table below. Sheet steel choices are compared on the galvanized or DKP sheet steel page, lock alternatives on the lock systems page. Maintenance steps that extend the door's life are on the care and lifespan page, and the coverage itself on the warranty and service page.

Frequently Asked Questions

How is the price of the C-TR700 determined?

We do not publish a list price, because each door is made to measure. The total is set by the size of the opening and the cladding, glass and lock you select. After a free survey we provide a written quote itemized line by line; what moves the price is explained on our steel door prices page.

Can the color of the C-TR700 be changed?

It can. Dark walnut is only the finish photographed, not a fixed choice — you can pick from the alternatives on our cladding options page.

Do I need to take the measurements myself?

We take the measurements during the survey; nothing is required from you. Measurements come from the door opening, not the existing leaf — the method is described on our how to measure page.

How can I order the C-TR700 model?

You can fill out the pre-order form on our site or reach us at 0532 689 21 46. Mentioning product code C-TR700 in your request speeds things up. You can browse other steel door models on our steel door models page.

Specifications

Product code	C-TR700
Category	Steel Door Models
Leaf construction	single leaf
Color / finish	dark walnut
Surface pattern	oval medallion relief and lower floral motif
Handle	gold knocker and horizontal handle
Upper section	frame with pediment
Design language	classic
Glass	Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant)
Place of use	Flat entrance door
Sound and heat insulation	Insulation via infill material and gasket system
Interior surface	Interior panel in any desired color and finish
Sheet thickness	Frame 2 mm (0.079"), leaf 1.5+1.5 mm (0.118" total) DKP steel sheet (Ereğli A1)
Frame	Ereğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent
Frame reinforcement	Lock and hinge areas reinforced with 3 mm (0.118") DKP steel sheet
Leaf	Ereğli A1 grade 1.5 mm (0.059") + 1.5 mm (0.059") omega-bent, monoblock-reinforced pan system
Leaf reinforcement	Lock and hinge area reinforced with 3 mm (0.118") angle bar
Leaf thickness	Bare metal 70 mm (2.76") — 90 mm (3.54") in total
Infill	80 kg/m³ rock wool
Lock surround	integrated with 1 mm (0.039") grade 304 stainless steel
Hinge	3 adjustable 20 mm (0.787") ball-bearing pin hinges
Hinge reinforcement	5 mm (0.197") thick flat bar
Fixed pin	5 units on the hinge side, 20 mm (0.787") diameter
Gasket	Silicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf (insect-, dust- and airtight)
Surface finish	10 mm (0.394") Camsan first-grade iroko
Finish options	Powder coating, natural wood, marine plywood, iroko wood or composite compact laminate
Varnish	Polyurethane infill, 90-micron coverage rating
Polish	Akzo Nobel
Accessories	first-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions)
Installation	One-piece inner/outer frame, clamp-grip jointing, fastened with M8 bolts
Frame-to-wall gap	1 cm (0.394"), filled with polyurethane foam
Production	Manufactured to custom on-site measurements
Warranty	Unlimited coverage for manufacturing defects — 2-year official warranty certificate
Lock system	Optional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock

Frequently Asked Questions

What is the lead time for a custom villa door?

Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.

How are steel doors packaged for sea freight export?

Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.

What measurements do you need to quote?

The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.

Can you manufacture to imperial (inch) dimensions?

Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.

Who installs the door at the destination?

Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.

What export documents travel with the shipment?

Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
