Oval Medallion Red Walnut Villa Door BD-TR136

Product CodeBD-TR136

Classic red walnut villa door worked with oval medallion carvings. Product code: BD-TR136. Made to measure after an on-site survey.

Leaf construction: single leaf + narrow fixed leaf
Color / finish: red walnut
Glass: Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant)
Handle: silver knocker and handle
Design language: classic villa
Upper section: frame with dentil cornice

Share this model

Pre-Order & Price Request

This model is made to measure. Leave your request and we'll call you to arrange a site survey.

Product codeBD-TR136

Survey and measurement are free
Same-day response
Made in our own factory
Lifetime manufacturing warranty

+90 532 689 21 46 WhatsApp

Download this model's PDF spec sheet

Worldwide shipping & export

Made in our own factory

Lifetime manufacturing warranty

#villa door #villa steel door #bd-tr136 #made-to-measure steel door #classic design #wood tone #single leaf

BD-TR136 is a villa steel door model distinguished by its classic red walnut design worked with oval medallion carvings. Like every door we make, this model is produced to measure — no leaves are supplied from stock.

Product Code: BD-TR136

Surface and Pediment Layout

The leaf structure is a single leaf with a narrow fixed sidelight. The leaf carries embossed oval medallion carvings. The finish is a red walnut tone.

The upper section features a frame with a dentil cornice. Silver knocker and handle were chosen for this model. Color, pattern and handle choices can be tailored to your project; the cladding options page compares what is available.

Its design language is defined as classic villa.

Which Entrances Suit This Model?

It is chosen primarily for garden homes and villa entrances. Thanks to the side sections, wide door openings are closed with a single assembly. We compare where a villa door differs from a building entrance door on our villa door vs. building entrance door page.

From Measurement to Installation

Measurements are taken from the door opening, not the existing leaf; we describe the process step by step on our how to measure page. Frame, sheet thickness, infill and lock values are listed in the specification table below. Sheet steel choices are compared on the galvanized or DKP sheet steel page, lock alternatives on the lock systems page. After delivery, our warranty and service coverage applies; see the care and lifespan page for keeping the surface protected.

Frequently Asked Questions

How much is the BD-TR136?

We do not publish a list price, because each door is made to measure. The total is set by the size of the opening and the cladding, glass and lock you select. After a free survey we provide a written quote itemized line by line; what moves the price is explained on our steel door prices page.

Can the color of the BD-TR136 be changed?

Yes — the color is not fixed. The catalog shows red walnut, but the cladding is decided per project; on our cladding options page we cover which surface works best where.

How is the BD-TR136 measured?

Our survey team measures on site. If you would still like to know the process, our how to measure page explains the three points we measure from.

How can I order the BD-TR136 model?

You can fill out the pre-order form on our site or reach us at 0532 689 21 46. Mentioning product code BD-TR136 in your request speeds things up. You can browse other villa steel door models on our villa steel door models page.

Specifications

Product code	BD-TR136
Category	Villa Steel Door Models
Leaf construction	single leaf + narrow fixed leaf
Color / finish	red walnut
Surface pattern	carved oval medallion reliefs
Handle	silver knocker and handle
Upper section	frame with dentil cornice
Design language	classic villa
Glass	Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant)
Access system	Optional card or keypad entry
Sheet thickness	Frame 2 mm (0.079"), leaf 1.5+1.5 mm (0.118" total) DKP steel sheet (Ereğli A1)
Frame	Ereğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent
Frame reinforcement	Lock and hinge areas reinforced with 3 mm (0.118") DKP steel sheet
Leaf	Ereğli A1 grade 1.5 mm (0.059") + 1.5 mm (0.059") omega-bent, monoblock-reinforced pan system
Leaf reinforcement	Lock and hinge area reinforced with 3 mm (0.118") angle bar
Leaf thickness	Bare metal 70 mm (2.76") — 90 mm (3.54") in total
Infill	80 kg/m³ rock wool
Lock surround	integrated with 1 mm (0.039") grade 304 stainless steel
Hinge	3 adjustable 20 mm (0.787") ball-bearing pin hinges
Hinge reinforcement	5 mm (0.197") thick flat bar
Fixed pin	5 units on the hinge side, 20 mm (0.787") diameter
Gasket	Silicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf (insect-, dust- and airtight)
Surface finish	10 mm (0.394") Camsan first-grade iroko
Finish options	Powder coating, natural wood, marine plywood, iroko wood or composite compact laminate
Varnish	Polyurethane infill, 90-micron coverage rating
Polish	Akzo Nobel
Accessories	first-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions)
Installation	One-piece inner/outer frame, clamp-grip jointing, fastened with M8 bolts
Frame-to-wall gap	1 cm (0.394"), filled with polyurethane foam
Production	Manufactured to custom on-site measurements
Warranty	Unlimited coverage for manufacturing defects — 2-year official warranty certificate
Lock system	Optional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock

Frequently Asked Questions

What is the lead time for a custom villa door?

Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.

How are steel doors packaged for sea freight export?

Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.

What measurements do you need to quote?

The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.

Can you manufacture to imperial (inch) dimensions?

Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.

Who installs the door at the destination?

Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.

What export documents travel with the shipment?

Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
