Paneled Red Walnut Steel Door C-TR707

Product CodeC-TR707

Red walnut classic paneling with a gold lantern-shaped knocker. Product code: C-TR707. Made to measure after an on-site survey.

Leaf construction: single leaf
Color / finish: red walnut
Glass: Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant)
Handle: gold lantern knocker, horizontal stainless steel handle
Design language: classic

Share this model

Pre-Order & Price Request

This model is made to measure. Leave your request and we'll call you to arrange a site survey.

Product codeC-TR707

Survey and measurement are free
Same-day response
Made in our own factory
Lifetime manufacturing warranty

+90 532 689 21 46 WhatsApp

Download this model's PDF spec sheet

Worldwide shipping & export

Made in our own factory

Lifetime manufacturing warranty

#steel door #flat entrance steel door #c-tr707 #classic #made-to-measure steel door #classic design #wood tone #single leaf

Red walnut classic paneling with a gold lantern-shaped knocker — that is what sets the steel door C-TR707 apart. Like all our doors, this model is made to measure — no leaf comes ready-made from stock. The image shows the red walnut finish.

Product code: C-TR707

Classic Surface Craftsmanship

The model is configured as a single leaf. The surface work is classic paneling, applied in red walnut.

The hardware pairs a gold lantern knocker with a horizontal stainless steel handle. Color, pattern, and handle can all be changed to suit your project; the cladding options page compares what's available.

The design language is classic.

Suitable Entrances

It is chosen primarily for apartment flats and residence apartments. The single-leaf layout adapts directly to standard door openings.

Production and Installation Process

Production starts with measurements taken on site. How the door opening is measured is explained on the how measurements are taken page; material choices are covered on the galvanized or DKP sheet steel and lock systems pages. This model's technical specifications are in the table below. After installation, the care and lifespan guidance and warranty and service terms apply.

Frequently Asked Questions

How much does the C-TR707 model cost?

We can't quote a price without measuring. The size of the door opening and your choice of cladding, glass, and lock directly affect the total; the site survey is free, followed by an itemized quote. See steel door prices for details.

Can I have this model in a color other than red walnut?

It can be done. Red walnut is simply the finish in the photo, not a fixed choice — you can pick from the alternatives on the cladding options page.

How is C-TR707 measured?

Our survey team measures on site. Still, if you'd like to know the process, the how measurements are taken page explains the three points we measure from.

How do I get a quote for C-TR707?

You can fill in the pre-order form on our site or reach us on 0532 689 21 46. Mentioning the product code C-TR707 in your request speeds things up. You can browse other steel door models on the steel door models page.

Specifications

Product code	C-TR707
Category	Steel Door Models
Leaf construction	single leaf
Color / finish	red walnut
Surface pattern	classic panel
Handle	gold lantern knocker, horizontal stainless steel handle
Design language	classic
Glass	Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant)
Place of use	Flat entrance door
Sound and heat insulation	Insulation via infill material and gasket system
Interior surface	Interior panel in any desired color and finish
Sheet thickness	Frame 2 mm (0.079"), leaf 1.5+1.5 mm (0.118" total) DKP steel sheet (Ereğli A1)
Frame	Ereğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent
Frame reinforcement	Lock and hinge areas reinforced with 3 mm (0.118") DKP steel sheet
Leaf	Ereğli A1 grade 1.5 mm (0.059") + 1.5 mm (0.059") omega-bent, monoblock-reinforced pan system
Leaf reinforcement	Lock and hinge area reinforced with 3 mm (0.118") angle bar
Leaf thickness	Bare metal 70 mm (2.76") — 90 mm (3.54") in total
Infill	80 kg/m³ rock wool
Lock surround	integrated with 1 mm (0.039") grade 304 stainless steel
Hinge	3 adjustable 20 mm (0.787") ball-bearing pin hinges
Hinge reinforcement	5 mm (0.197") thick flat bar
Fixed pin	5 units on the hinge side, 20 mm (0.787") diameter
Gasket	Silicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf (insect-, dust- and airtight)
Surface finish	10 mm (0.394") Camsan first-grade iroko
Finish options	Powder coating, natural wood, marine plywood, iroko wood or composite compact laminate
Varnish	Polyurethane infill, 90-micron coverage rating
Polish	Akzo Nobel
Accessories	first-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions)
Installation	One-piece inner/outer frame, clamp-grip jointing, fastened with M8 bolts
Frame-to-wall gap	1 cm (0.394"), filled with polyurethane foam
Production	Manufactured to custom on-site measurements
Warranty	Unlimited coverage for manufacturing defects — 2-year official warranty certificate
Lock system	Optional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock

Frequently Asked Questions

What is the lead time for a custom villa door?

Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.

How are steel doors packaged for sea freight export?

Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.

What measurements do you need to quote?

The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.

Can you manufacture to imperial (inch) dimensions?

Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.

Who installs the door at the destination?

Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.

What export documents travel with the shipment?

Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
