Red walnut paneled leaf with a narrow fixed side panel. Product code: BD-TR33. Made to measure after an on-site survey.
- Leaf construction
- single leaf + narrow fixed leaf
- Color / finish
- red walnut
- Glass
- Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant)
- Handle
- silver knocker and handle
- Design language
- classic villa
Pre-Order & Price Request
This model is made to measure. Leave your request and we'll call you to arrange a site survey.
- Survey and measurement are free
- Same-day response
- Made in our own factory
- Lifetime manufacturing warranty
This villa steel door carries the code BD-TR33: a red walnut paneled leaf with a narrow fixed side panel. It is not sold in standard sizes; your entrance is measured on site and the leaf is manufactured to fit. The catalog finish is a red walnut tone.
Product code: BD-TR33
Carving and Panel Details
The door is structured as a single leaf with a narrow fixed side panel. The leaf face is worked as paneling, finished in a red walnut tone.
The hardware is a silver knocker and handle set. The finish shown is the catalog choice — a different cladding can be selected from the cladding options.
The design language is classic villa.
Which Entrance Does It Suit?
It is chosen primarily for houses with gardens and residence apartments. Thanks to the side sections, wide door openings are closed with a single unit. We compare where a villa door and a building entrance door part ways on the villa door vs. building entrance door page.
Production and Installation Process
We take the measurements during the site survey — based on the door opening, not the existing leaf; the method is explained on the how measurements are taken page. You'll find this model's frame, leaf, and lock specifications in the table below; the lock systems and galvanized or DKP sheet steel pages cover the options in detail. The maintenance steps that extend the door's life are on the care and lifespan page, and what's covered is on the warranty and service page.
Frequently Asked Questions
How much is BD-TR33?
There is no fixed price — since every leaf is made to measure, the total depends on the dimensions, the cladding, and the lock you choose. After the survey we send a written, itemized quote. We break down the line items on the steel door prices page.
Can the color of the BD-TR33 door be changed?
Yes, the color isn't fixed. It appears in red walnut in the catalog, but the cladding is decided per project; on the cladding options page we've written up which surface works best where.
How is BD-TR33 measured?
Measuring is our job. We measure the clear width of the door opening, the height from the finished floor, and the wall thickness; the details are on the how measurements are taken page.
How do I order the BD-TR33 model?
You can fill in the pre-order form on our site or reach us on 0532 689 21 46. Mentioning the product code BD-TR33 in your request speeds things up. You can browse other villa steel door models on the villa steel door models page.
Specifications
| Product code | BD-TR33 |
| Category | Villa Steel Door Models |
| Leaf construction | single leaf + narrow fixed leaf |
| Color / finish | red walnut |
| Surface pattern | panel (cassette panel) |
| Handle | silver knocker and handle |
| Design language | classic villa |
| Glass | Şişecam 5+5 mm (0.394" total) laminated glass (impact resistant) |
| Access system | Optional card or keypad entry |
| Sheet thickness | Frame 2 mm (0.079"), leaf 1.5+1.5 mm (0.118" total) DKP steel sheet (Ereğli A1) |
| Frame | Ereğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent |
| Frame reinforcement | Lock and hinge areas reinforced with 3 mm (0.118") DKP steel sheet |
| Leaf | Ereğli A1 grade 1.5 mm (0.059") + 1.5 mm (0.059") omega-bent, monoblock-reinforced pan system |
| Leaf reinforcement | Lock and hinge area reinforced with 3 mm (0.118") angle bar |
| Leaf thickness | Bare metal 70 mm (2.76") — 90 mm (3.54") in total |
| Infill | 80 kg/m³ rock wool |
| Lock surround | integrated with 1 mm (0.039") grade 304 stainless steel |
| Hinge | 3 adjustable 20 mm (0.787") ball-bearing pin hinges |
| Hinge reinforcement | 5 mm (0.197") thick flat bar |
| Fixed pin | 5 units on the hinge side, 20 mm (0.787") diameter |
| Gasket | Silicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf (insect-, dust- and airtight) |
| Surface finish | 10 mm (0.394") Camsan first-grade iroko |
| Finish options | Powder coating, natural wood, marine plywood, iroko wood or composite compact laminate |
| Varnish | Polyurethane infill, 90-micron coverage rating |
| Polish | Akzo Nobel |
| Accessories | first-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions) |
| Installation | One-piece inner/outer frame, clamp-grip jointing, fastened with M8 bolts |
| Frame-to-wall gap | 1 cm (0.394"), filled with polyurethane foam |
| Production | Manufactured to custom on-site measurements |
| Warranty | Unlimited coverage for manufacturing defects — 2-year official warranty certificate |
| Lock system | Optional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock |
Frequently Asked Questions
What is the lead time for a custom villa door?
Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.
How are steel doors packaged for sea freight export?
Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.
What measurements do you need to quote?
The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.
Can you manufacture to imperial (inch) dimensions?
Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.
Who installs the door at the destination?
Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.
What export documents travel with the shipment?
Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
- • A free on-site survey is carried out before ordering to measure the door opening.
- • Production follows the dimensions and finish you approve after the survey.
- • Installation is carried out on-site by our own team.
- • Our warranty against manufacturing and workmanship defects is unlimited; an official 2-year warranty document is provided on delivery.
- • Price incl. VAT: %20 Includes VAT.
