Dense Baroque Russet-Brown Building Entrance Door TR532

Product CodeTR532

Russet-brown body with large glass panels worked in dense white wrought-iron scrollwork. Product code: TR532. Manufactured to measure, following an on-site survey.

Leaf construction
double leaf
Color / finish
reddish brown
Handle
curved stainless steel handle
Design language
classic wrought-iron
Share this model

Pre-Order & Price Request

This model is made to measure. Leave your request and we'll call you to arrange a site survey.

Product codeTR532

This is here to block automated submissions — it only takes a second.

  • Survey and measurement are free
  • Same-day response
  • Made in our own factory
  • Lifetime manufacturing warranty
Download this model's PDF spec sheet
Worldwide shipping & export
Made in our own factory
Lifetime manufacturing warranty

The TR532 richly baroque russet-brown building entrance door is produced with large glass panels worked in dense white wrought-iron scrollwork over a russet-brown body. It isn't sold in ready-made sizes; your entrance is measured on site and the leaf is manufactured to that measurement. The finish shown in the photo is russet-brown cladding.

Product Code: TR532

Leaf and Glass Layout

It's produced as a double leaf. The surface features dense baroque wrought-iron scrollwork. The surface is finished in russet brown.

The glazing takes the form of two large glass panels with dense white wrought-iron scrollwork. It's finished with a curved stainless handle. The finish shown is the catalog choice — a different cladding can be selected from our cladding options.

The design language is described as classic wrought-iron.

Where Is It Used?

Housing-estate blocks and residential complexes are the typical settings for this model. Thanks to the side sections, wide door openings are covered by a single, unified design. The difference between the two types isn't just size — we've detailed it on our villa door vs. building entrance door page.

From Measurement to Installation

We take the measurement during the on-site survey — it's based on the door opening, not the existing leaf; the method is explained on our how measurements are taken page. You'll find this model's frame, leaf and lock specifications in the table below; our lock systems and galvanized vs. cold-rolled steel pages detail the options. After delivery, our warranty and service terms apply — see our care and lifespan page for how to protect the finish.

Frequently Asked Questions

How much does TR532 cost?

We don't publish a list price, because the door is built to measure. The amount is set by the size of the door opening plus the cladding, glass and lock you choose. After a free survey, we provide a written, itemized quote; we've explained what affects the price on our steel door prices page.

Can TR532 be made in a different color?

It can be. Russet brown is simply the finish shown in the photo, not a fixed choice — you can pick from the alternatives on our cladding options page.

Can the glass pattern be different?

Yes. The glass shown is this model's catalog finish; it can be produced in a different color and pattern as long as Şişecam 5+5 mm laminated glass is used. A version without glass is also possible.

How does the measuring stage work when ordering TR532?

Measuring is our job. We measure the clear width and height of the door opening from the finished floor, plus the wall thickness; details are on our how measurements are taken page.

How do I get a quote for TR532?

You can fill out the pre-order form on the site, or reach us at 0532 689 21 46. Mentioning the TR532 product code in your request speeds up the process. You can browse other building entrance door models on our building entrance door models page.

Specifications

Product codeTR532
CategoryBuilding Entrance Steel Door Models
Leaf constructiondouble leaf
Color / finishreddish brown
Surface patterndense baroque wrought iron
Handlecurved stainless steel handle
Design languageclassic wrought-iron
Push-to-open systemself-closing system within 6 seconds
Door closersize 5 door closer
Access systemOptional card or keypad entry
Sheet thicknessFrame 2 mm (0.079"), leaf 1.5+1.5 mm (0.118" total) DKP steel sheet (Ereğli A1)
FrameEreğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent
Frame reinforcementLock and hinge areas reinforced with 3 mm (0.118") DKP steel sheet
LeafEreğli A1 grade 1.5 mm (0.059") + 1.5 mm (0.059") omega-bent, monoblock-reinforced pan system
Leaf reinforcementLock and hinge area reinforced with 3 mm (0.118") angle bar
Leaf thicknessBare metal 70 mm (2.76") — 90 mm (3.54") in total
Infill80 kg/m³ rock wool
Lock surroundintegrated with 1 mm (0.039") grade 304 stainless steel
Hinge3 adjustable 20 mm (0.787") ball-bearing pin hinges
Hinge reinforcement5 mm (0.197") thick flat bar
Fixed pin5 units on the hinge side, 20 mm (0.787") diameter
GasketSilicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf (insect-, dust- and airtight)
Surface finish10 mm (0.394") Camsan first-grade iroko
Finish optionsPowder coating, natural wood, marine plywood, iroko wood or composite compact laminate
VarnishPolyurethane infill, 90-micron coverage rating
PolishAkzo Nobel
Accessoriesfirst-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions)
InstallationOne-piece inner/outer frame, clamp-grip jointing, fastened with M8 bolts
Frame-to-wall gap1 cm (0.394"), filled with polyurethane foam
ProductionManufactured to custom on-site measurements
WarrantyUnlimited coverage for manufacturing defects — 2-year official warranty certificate
Lock systemOptional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock
Glass sectiontwo large glass panes with ornate white wrought iron scrollwork
Glass typeŞişecam 5+5 mm (0.394" total) laminated glass (impact resistant)

Frequently Asked Questions

What is the lead time for a custom villa door?

Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.

How are steel doors packaged for sea freight export?

Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.

What measurements do you need to quote?

The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.

Can you manufacture to imperial (inch) dimensions?

Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.

Who installs the door at the destination?

Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.

What export documents travel with the shipment?

Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
