Horizontal-Slat Orange-Honey Villa Door BD-TR101

Product CodeBD-TR101

A honey-toned slatted leaf in a black frame, with a gold-tone vertical handle. Product code: BD-TR101. Custom-built to measure after an on-site survey.

Leaf construction
single leaf + double sidelight
Color / finish
orange-honey wood + black frame
Handle
gold-colored vertical handle
Design language
modern villa
Share this model

Pre-Order & Price Request

This model is made to measure. Leave your request and we'll call you to arrange a site survey.

Product codeBD-TR101

This is here to block automated submissions — it only takes a second.

  • Survey and measurement are free
  • Same-day response
  • Made in our own factory
  • Lifetime manufacturing warranty
Download this model's PDF spec sheet
Worldwide shipping & export
Made in our own factory
Lifetime manufacturing warranty

The BD-TR101 horizontal-slat orange-honey villa door is built with a honey-toned slatted leaf set in a black frame, finished with a gold-tone vertical handle. It's manufactured to measure — whatever the width and height of your entrance, the leaf is built to match.

Product Code: BD-TR101

Surface and Glass Panel

The panel layout is a single leaf with double side glass panels. The panel shows horizontal slats and black vertical bands. The catalog color is an orange-honey wood with a black frame tone.

The glass layout is designed with wide side panels. It is completed with a gold-tone vertical handle. The finish and hardware aren't fixed; the door can be produced with any of the alternatives on the finish options page.

The design language is best described as modern villa.

Who Is This Model For?

It's primarily chosen for villa entrances and houses with gardens. Because the side sections widen the opening, it suits wide-fronted entrances rather than narrow ones — and it lets daylight into the hall as well. We compare where villa doors and building entrance doors differ on the villa doors vs. building entrance doors page.

From Measurement to Installation

We take the measurement during the survey — it's based on the door opening, not the existing leaf; the method is explained on the how we take the measurement page. You'll find this model's frame, leaf, and lock specifications in the table below; the lock systems and galvanized vs. cold-rolled steel pages go into the options in more detail. After delivery, the warranty and service coverage applies; see the maintenance and lifespan page for how to protect the finish.

Frequently Asked Questions

How is the price of BD-TR101 determined?

We don't publish a list price, because every door is built to measure. The final amount depends on the size of the door opening, the finish, glass, and lock you choose. After a free on-site survey, we provide a written, itemized quote — we explain what drives the price on the steel door prices page.

Can BD-TR101 be made in a different color?

Yes, the color isn't fixed. The catalog shows orange-honey wood with a black frame, but the finish is chosen to suit each project; on the finish options page we cover which surface works best where.

Can the glass be changed on the BD-TR101 model?

Yes. The glass shown is the catalog's default for this model; as long as Şişecam 5+5 mm laminated glass is used, it can be produced in different colors and patterns. Production without glass is also possible.

How does the measurement stage work when ordering BD-TR101?

Our survey team measures on site. If you'd still like to know how it works, we've explained on the how we take the measurement page which three points we measure.

How can I order the BD-TR101 model?

You can fill out the pre-order form on the site, or call us at 0532 689 21 46. Mentioning the BD-TR101 product code in your request speeds things up. You can browse other models on the villa steel door models page.

Specifications

Product codeBD-TR101
CategoryVilla Steel Door Models
Leaf constructionsingle leaf + double sidelight
Color / finishorange-honey wood + black frame
Surface patternhorizontal slats and black vertical bands
Handlegold-colored vertical handle
Design languagemodern villa
Access systemOptional card or keypad entry
Sheet thicknessFrame 2 mm (0.079"), leaf 1.5+1.5 mm (0.118" total) DKP steel sheet (Ereğli A1)
FrameEreğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent
Frame reinforcementLock and hinge areas reinforced with 3 mm (0.118") DKP steel sheet
LeafEreğli A1 grade 1.5 mm (0.059") + 1.5 mm (0.059") omega-bent, monoblock-reinforced pan system
Leaf reinforcementLock and hinge area reinforced with 3 mm (0.118") angle bar
Leaf thicknessBare metal 70 mm (2.76") — 90 mm (3.54") in total
Infill80 kg/m³ rock wool
Lock surroundintegrated with 1 mm (0.039") grade 304 stainless steel
Hinge3 adjustable 20 mm (0.787") ball-bearing pin hinges
Hinge reinforcement5 mm (0.197") thick flat bar
Fixed pin5 units on the hinge side, 20 mm (0.787") diameter
GasketSilicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf (insect-, dust- and airtight)
Surface finish10 mm (0.394") Camsan first-grade iroko
Finish optionsPowder coating, natural wood, marine plywood, iroko wood or composite compact laminate
VarnishPolyurethane infill, 90-micron coverage rating
PolishAkzo Nobel
Accessoriesfirst-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions)
InstallationOne-piece inner/outer frame, clamp-grip jointing, fastened with M8 bolts
Frame-to-wall gap1 cm (0.394"), filled with polyurethane foam
ProductionManufactured to custom on-site measurements
WarrantyUnlimited coverage for manufacturing defects — 2-year official warranty certificate
Lock systemOptional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock
Glass sectionwide sidelights
Glass typeŞişecam 5+5 mm (0.394" total) laminated glass (impact resistant)

Frequently Asked Questions

What is the lead time for a custom villa door?

Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.

How are steel doors packaged for sea freight export?

Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.

What measurements do you need to quote?

The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.

Can you manufacture to imperial (inch) dimensions?

Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.

Who installs the door at the destination?

Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.

What export documents travel with the shipment?

Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
