Iron Railing Black Building Entrance Door TR515

Product CodeTR515

A fully glazed double leaf with black framing, a clean modern line for apartment entrances. Product code: TR515. Made to measure after an on-site survey.

Leaf construction
double leaf
Color / finish
black
Handle
curved stainless steel handle
Design language
modern
Share this model

Pre-Order & Price Request

This model is made to measure. Leave your request and we'll call you to arrange a site survey.

Product codeTR515

This is here to block automated submissions — it only takes a second.

  • Survey and measurement are free
  • Same-day response
  • Made in our own factory
  • Lifetime manufacturing warranty
Download this model's PDF spec sheet
Worldwide shipping & export
Made in our own factory
Lifetime manufacturing warranty

A fully glazed double leaf with black framing — a clean modern line for apartment building entrances. It appears in the catalog under code TR515. Production starts after your order: first a site survey, then the leaf is built to fit the door opening. The catalog finish is a black tone.

Product Code: TR515

Leaf and Glass Layout

The leaf layout is double leaf. The leaf displays an iron railing detail. The catalog color is a black tone.

The glazing is resolved as full-height clear glass. The model is fitted with a curved stainless steel handle. Color, pattern, and handle choices can be adapted to your project; the options are compared on the cladding options page.

Who Is This Model For?

Apartment building entrances and commercial building entrances are this model's typical settings. Because the side sections widen the opening, it suits wide-fronted entrances rather than narrow ones; it also brings daylight into the hall. We compare where a villa door and a building entrance door part ways on the villa door vs. building entrance door page.

From Measurement to Installation

We take the measurements during the site survey — based on the door opening, not the existing leaf; the method is explained on the how doors are measured page. You will find this model's frame, leaf, and lock specifications in the table below; the lock systems and galvanized or DKP sheet steel pages cover the options in detail. After delivery, warranty and service coverage applies; see the care and lifespan page for protecting the surface.

Frequently Asked Questions

How is the price of TR515 determined?

We cannot quote a price before taking measurements. The size of the door opening and your choice of cladding, glass, and lock directly affect the total; the site survey is free, and an itemized quote follows. See steel door prices for details.

Can the color of TR515 be changed?

Yes — the color is not fixed. The catalog shows black, but the cladding is decided per project; on the cladding options page we cover which surface works best where.

Can the glass in TR515 be changed?

Yes. The glass shown is this model's catalog finish; provided Şişecam 5+5 mm laminated glass is used, it can be produced in different colors and patterns. A glass-free version is also possible.

Do I need to take the measurements myself?

We take the measurements during the site survey; nothing is required on your part. Measurements are taken from the door opening, not the existing leaf — we explain the method on the how doors are measured page.

How can I order model TR515?

You can fill in the pre-order form on our website or call us on 0532 689 21 46. Mentioning the product code TR515 in your request speeds things up. You can browse other building entrance door designs on the building entrance door models page.

Specifications

Product codeTR515
CategoryBuilding Entrance Steel Door Models
Leaf constructiondouble leaf
Color / finishblack
Surface patterniron railing detail
Handlecurved stainless steel handle
Design languagemodern
Push-to-open systemself-closing system within 6 seconds
Door closersize 5 door closer
Access systemOptional card or keypad entry
Sheet thicknessFrame 2 mm (0.079"), leaf 1.5+1.5 mm (0.118" total) DKP steel sheet (Ereğli A1)
FrameEreğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent
Frame reinforcementLock and hinge areas reinforced with 3 mm (0.118") DKP steel sheet
LeafEreğli A1 grade 1.5 mm (0.059") + 1.5 mm (0.059") omega-bent, monoblock-reinforced pan system
Leaf reinforcementLock and hinge area reinforced with 3 mm (0.118") angle bar
Leaf thicknessBare metal 70 mm (2.76") — 90 mm (3.54") in total
Infill80 kg/m³ rock wool
Lock surroundintegrated with 1 mm (0.039") grade 304 stainless steel
Hinge3 adjustable 20 mm (0.787") ball-bearing pin hinges
Hinge reinforcement5 mm (0.197") thick flat bar
Fixed pin5 units on the hinge side, 20 mm (0.787") diameter
GasketSilicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf (insect-, dust- and airtight)
Surface finish10 mm (0.394") Camsan first-grade iroko
Finish optionsPowder coating, natural wood, marine plywood, iroko wood or composite compact laminate
VarnishPolyurethane infill, 90-micron coverage rating
PolishAkzo Nobel
Accessoriesfirst-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions)
InstallationOne-piece inner/outer frame, clamp-grip jointing, fastened with M8 bolts
Frame-to-wall gap1 cm (0.394"), filled with polyurethane foam
ProductionManufactured to custom on-site measurements
WarrantyUnlimited coverage for manufacturing defects — 2-year official warranty certificate
Lock systemOptional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock
Glass sectionfull-height clear glass panels
Glass typeŞişecam 5+5 mm (0.394" total) laminated glass (impact resistant)

Frequently Asked Questions

What is the lead time for a custom villa door?

Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.

How are steel doors packaged for sea freight export?

Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.

What measurements do you need to quote?

The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.

Can you manufacture to imperial (inch) dimensions?

Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.

Who installs the door at the destination?

Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.

What export documents travel with the shipment?

Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
