Vertical Louvered Black-to-Walnut Pivot Door BY-257
Vertical Louvered Black-to-Walnut Pivot Door. Product code: BY-257. Made to measure after an on-site survey.
- Leaf construction
- single leaf
- Color / finish
- black
- Design language
- modern pivot
Pre-Order & Price Request
This model is made to measure. Leave your request and we'll call you to arrange a site survey.
- Survey and measurement are free
- Same-day response
- Made in our own factory
- Lifetime manufacturing warranty
BY-257 is the product code of the vertical louvered black-to-walnut pivot door in our catalog. It is not sold in stock sizes; your entrance is measured on site and the leaf is built to that measurement. The image shows the black finish.
Product Code: BY-257
Leaf Surface
The model is configured as a single leaf. It features a vertical louvered leaf with a walnut transition. The surface is finished in black.
The finish in the image is the catalog choice — a different finish can be selected from our surface finish options.
The design language is best described as modern pivot.
Where Is It Used?
It is chosen primarily for hotel and showroom entrances and villa entrances. The single-leaf layout adapts readily to conventional door openings. The leaf turns on bearings set into the floor and the head of the frame, making sizes possible that hinges could never carry. In return, it needs swing clearance in front of and behind the door. Our when to choose a pivot door page explains which entrances are suitable.
From Measurement to Installation
Measurements are taken from the door opening, not the existing leaf; we explain the process step by step on the how measurements are taken page. Frame, sheet thickness, infill and lock specifications are listed in the table below. Sheet steel choices are compared on the galvanized or DKP sheet steel page, and lock alternatives on the lock systems page. After delivery, our warranty and service coverage applies; see the care and lifespan page for keeping the surface in good condition.
Frequently Asked Questions
How much does the BY-257 model cost?
We publish no list price, because every door is made to measure. The total is determined by the size of the door opening and the finish, glass and lock you select. After a free survey we provide a written quotation itemized line by line; what moves the price is explained on our steel door prices page.
Can I have this model in a color other than black?
Yes, it can. Black is simply the finish shown in the photo, not a fixed choice — you can pick from the alternatives on our surface finish options page.
How does measuring work when ordering the BY-257?
Our survey team measures on site. If you would still like to know how it works, the how measurements are taken page explains the three points we measure from.
How do I get a quote for the BY-257?
You can fill in the pre-order form on our website or reach us on 0532 689 21 46. Quoting product code BY-257 in your request helps speed things up. You can browse our other pivot steel doors on the pivot steel door models page.
Specifications
| Product code | BY-257 |
| Category | Pivot Steel Door Models |
| Color / finish | black |
| Design language | modern pivot |
| Leaf construction | single leaf |
| Rotation system | Floor and ceiling bearings — no conventional hinges used |
| Load transfer | Leaf weight is transferred to the floor, not the frame |
| Rotation axis | Determined per project based on leaf width |
| Frame | Ereğli A1 grade 2 mm (0.079") DKP steel sheet, omega-bent |
| Leaf | Ereğli A1 grade 1.5 + 1.5 mm (0.118" total) omega-bent, monoblock-reinforced pan system |
| Leaf thickness | Bare metal 70 mm (2.76") — 90 mm (3.54") in total |
| Frame reinforcement | Lock area and bearing seats reinforced with 3 mm (0.118") DKP steel sheet |
| Leaf reinforcement | Lock area and pivot shaft surround reinforced with 3 mm (0.118") angle bar |
| Infill | 80 kg/m³ rock wool |
| Lock system | Optional hook-bolt, monoblock or central — Italian Mottura or Mul-T-Lock |
| Access system | Optional card, keypad or fingerprint entry |
| Gasket | Silicone-based rubber gasket on 3 sides of the frame, 4 sides of the leaf |
| Finish options | Powder coating, natural wood, marine plywood, iroko wood or composite compact laminate |
| Accessories | first-grade 304 stainless steel or 316 Häfele stainless brass (depending on climate conditions) |
| Floor preparation | Preparation is required where the bottom bearing sits — assessed during site survey |
| Required clearance | Clearance is needed in both directions, as the leaf swings both inward and outward |
| Installation | Installed by aligning the floor and ceiling bearings; one-piece frame, fixed with M8 bolts |
| Production | Manufactured to custom on-site measurements |
| Warranty | Unlimited coverage for manufacturing defects — 2-year official warranty certificate |
Frequently Asked Questions
What is the lead time for a custom villa door?
Production takes 20-25 days from the day the specification is approved. Custom detailing — carved cladding, oversized leaves, special glass — can extend that, and we confirm the date in writing before starting. Ocean freight time to the destination port is added on top.
How are steel doors packaged for sea freight export?
Each door is crated in a wooden case built to its own dimensions, with edge protection and corner blocks, then strapped to prevent movement inside the container. Full container loading is used for project quantities; single doors and small orders ship as groupage cargo.
What measurements do you need to quote?
The width, height and wall thickness of the rough opening, in millimetres or in inches — whichever your drawings use. Photographs of the opening from inside and outside help us confirm the swing direction and the frame detail. No site visit is needed.
Can you manufacture to imperial (inch) dimensions?
Yes. An opening given as 36 x 80 inches is manufactured to that dimension directly. Nothing is converted to a nearest metric size and rounded, so the door arrives at the size your drawing specifies.
Who installs the door at the destination?
Your own contractor. Every shipment includes an installation drawing and the frame fixing set, and the frame is designed to be set into the opening without special tooling.
What export documents travel with the shipment?
Commercial invoice, packing list and certificate of origin, plus whatever else the customs broker at the destination requires. Documentation is prepared before the container leaves the factory.
- • A free on-site survey is carried out before ordering to measure the door opening.
- • Production follows the dimensions and finish you approve after the survey.
- • Installation is carried out on-site by our own team.
- • Our warranty against manufacturing and workmanship defects is unlimited; an official 2-year warranty document is provided on delivery.
- • Price incl. VAT: %20 Includes VAT.
